Specifications

Basic Specifications

Color Range

W(2200K-6500K), R+G+B, RGBW, R+G+B+W

Working Voltage

AC 220V

Max. Power Consumption

72W(W, R+G+B, RGBW), 100W(R+G+B+W)

Light Source

36(W, RGBW), 12+12+12(R+G+B), 12+12+12+12(R+G+B+W) PCS High Power LEDs

LED chip Brand

Optional(Cree, OSRAM, Lumileds, Epistar, etc...)

CRI

80

Control

DMX512, ON/OFF

Source Life

50,000 h

Housing

High Strength Aluminum

Cover

Tempered glass

Weight

6.64Kg

Dimensions

265mm x 265mm x 248mm (L x W x H, exclude Mounting Bracket)

Installation

Installation with screws

Working Temperature

-40°C to 60°C

Storage Temperature

-40°C to 70°C

Protection Rating

IP66

Efficiency flux

70LM/W(White), 25LM/W(R+G+B), 35LM/W(RGBW)

Beam Angle

W-3030P7: 10°/15°/20°/30°/45°/60°/80°                                                                   RGB-3030P7 /CREE XP Series:                                             6°/8°/10°/15°/20°/30°/45°/60°/80°                                                                            3535:  30°/45°/60°/80°                                                  5050:17°/20°/30°/45°/60°
