Controller EXC-4000WG

Can install all current Windows operating systems and support various languages;

The playback software has sufficient interfaces in order to be compatible with other international common protocols and support customers' individual design requirements;

System Features

  • The controller output supports standard USITT DMX512/1990 general protocol and extended DMX protocol;

  • Global synchronization between multiple controllers can be achieved by receiving satellite signals, meeting the needs of customers to achieve synchronization of multiple controllers when multiple buildings cannot be connected;

  • The ADRI/PO end of the controller signal output can realize automatic addressing of DMX512 channels, and support DMX512AP-N/NB, UCS512, MY7221, WS2821 and other driver chips;

  • EXC-4000WG controller addressing signal output is compatible with output differential signals, which improves the transmission distance of addressing signals, which is conducive to long-distance transmission and effective addressing of addressing lines in project applications;

  • The system supports automatic, timing, and holiday preset effects playback;

  • The precise gamma correction algorithm is more in line with the human visual sensitivity characteristics, and the display colors are more full and rich, making the designer's animation or video effects perfect;

  • The maximum support for 120 frame change frequency to ensure the screen HD display and 3D display requirements;

  • The controller has buttons and an external remote control, which can realize program segment selection, overall brightness adjustment, white balance adjustment, playback speed adjustment, etc.;

  • LCD display module displays controller parameters and status in time;

  • 32-65536 gray level control, can truly restore the image color and details;

  • Support four-color lamps: energy saving and environmental protection, pure color;

  • SD card storage, the controller can support up to 32G, and can preset up to 99 program files;

  • Support remote online download and update offline programs;

  • Built-in animation test program, convenient for customers to debug and apply in the project;


Specifications

Input Voltage

AC 100V~240V

Maximum Power

15W

Length

283mm

Width

134mm

Height

45mm

Fixed Hole Spacing

268mm;68 mm

Standard accessories

Remote control×1 /SD card×1/AC power cord×1
