Narrow Beam Flood Light EXC-B50ABL

EXC-B50ABL series consists of full-color small-power spotlights with high-strength aluminum-alloy housing specially designed by EXC for outdoor landscape lighting. The product uses CREE lamp beads. Each light is a separate lighting pixel, and each pixel can realize 65536 grades gray scale changing. It could be used for illumination in specific areas or landscape wash lighting, applicable on building facades, bridges, stages, etc.


Specification Optical Parameters of Small LED Flood Light

  • LED Brand: CREE, Lumileds, Epistar, Taiwan series, Osram

  • Color: W

  • Beam Angle: 10°, 80°, and other angles optional

  • Source Life: 50,000h


Electrical Parameters of Small LED Flood Light EXC-B50ABL

  • Working Voltage: DC 24V

  • Rated Power: Maximum 3W


Control Parameters of Small LED Flood Light EXC-B50ABL

  • Control Method: ON OFF

  • Gray Scale: 8Bits/16Bits

  • Control System: EXC-ALL the lights control system


Structural Parameters of Small LED Flood Light EXC-B50ABL

  • Shell Material: High Strength Aluminum

  • Cover: Tempered glass

  • Surface Color: Black&White, Other colors optional

  • Structure Size: 67mm x 54mm x 77mm (L x W x H, exclude Mounting Bracket)

  • Total Weight: 0.4kg


Environmental Parameters of Small LED Flood Light EXC-B50ABL

  • Working Temperature: -40°C to 50°C

  • Storage Temperature: -40°C to 70°C

  • Protection rating: IP66

  • Application environment: Outdoor
